带密封薄壁球轴承JB系列
作者： 发布时间：2016-02-23 浏览次数：3776
| 型号 Type | 型号 Type | 尺寸 | 基本载荷 | Weight | |||||||
| (inch/mm) Dimension | Basic Cap.N | Kg | 国外型号 | 国外型号 | |||||||
| d | D | B | 径向Radial | 轴向Thrust | KAYDON | KAYDON | |||||
| Cor | Cr | Coa | Ca | ||||||||
| HNJB020XP0 | HNJB020CP0 | 2 | 2.625 | 0.3125 | 4130 | 2000 | 10400 | 5020 | 0.068 | JB020XP0 | JB020CP0 |
| 50.8 | 66.675 | 7.9375 | |||||||||
| HNJB025XP0 | HNJB025CP0 | 2.5 | 3.125 | 0.3125 | 5070 | 2310 | 12620 | 5730 | 0.086 | JB025XP0 | JB025CP0 |
| 63.5 | 79.375 | 7.9375 | |||||||||
| HNJB030XP0 | HNJB030CP0 | 3 | 3.625 | 0.3125 | 5960 | 2580 | 14890 | 6400 | 0.1 | JB030XP0 | JB030CP0 |
| 76.2 | 92.075 | 7.9375 | |||||||||
| HNJB035XP0 | HNJB035CP0 | 3.5 | 4.125 | 0.3125 | 6850 | 2800 | 17160 | 7070 | 0.122 | JB035XP0 | JB035CP0 |
| 88.9 | 104.775 | 7.9375 | |||||||||
| HNJB040XP0 | HNJB040CP0 | 4 | 4.625 | 0.3125 | 7780 | 3070 | 19430 | 7650 | 0.136 | JB040XP0 | JB040CP0 |
| 101.6 | 117.475 | 7.9375 | |||||||||
| HNJB042XP0 | HNJB042CP0 | 4.2 | 4.875 | 0.3125 | 8130 | 3160 | 20310 | 7910 | 0.141 | JB042XP0 | JB042CP0 |
| 107.95 | 123.825 | 7.9375 | |||||||||
| HNJB045XP0 | HNJB045CP0 | 4.5 | 5.125 | 0.3125 | 8670 | 3290 | 21690 | 8220 | 0.154 | JB045XP0 | JB045CP0 |
| 114.3 | 130.175 | 7.9375 | |||||||||
| HNJB047XP0 | HNJB047CP0 | 4.75 | 5.375 | 0.3125 | 9020 | 3380 | 22580 | 8450 | 0.159 | JB047XP0 | JB047CP0 |
| 120.65 | 136.525 | 7.9375 | |||||||||
| HNJB050XP0 | HNJB050CP0 | 5 | 5.625 | 0.3125 | 9560 | 3510 | 23910 | 8800 | 0.168 | JB050XP0 | JB050CP0 |
| 127 | 142.875 | 7.9375 | |||||||||
| HNJB055XP0 | HNJB055CP0 | 5.5 | 6.125 | 0.3125 | 10490 | 3730 | 26180 | 9340 | 0.181 | JB055XP0 | JB055CP0 |
| 139.7 | 155.575 | 7.9375 | |||||||||
| HNJB060XP0 | HNJB060CP0 | 6 | 6.625 | 0.3125 | 11380 | 3960 | 28450 | 9870 | 0.2 | JB060XP0 | JB060CP0 |
| 152.4 | 168.275 | 7.9375 | |||||||||
| HNJB065XP0 | HNJB065CP0 | 6.5 | 7.125 | 0.3125 | 12270 | 4130 | 30720 | 10400 | 0.213 | JB065XP0 | JB065CP0 |
| 165.1 | 180.975 | 7.9375 | |||||||||
