RMS/RLS/XLS轴承生产中
作者： 发布时间：2020-06-24 浏览次数：1528
| Part Number | Inner Diameter, d | Outer Diameter, D | Width, B | Dynamic Capacity, Cr. | Static Capacity, Cor. | Weight |
| RLS‑8 | 1 in. | 2‑1/4 in. | 5/8 in. | 1 N | 9 N | 0.42 lbs. |
| RLS‑8‑2RS | 1 in. | 2‑1/4 in. | 5/8 in. | ‑ N | ‑ N | 0.42 lbs. |
| RLS‑8‑2Z | 1 in. | 2‑1/4 in. | 5/8 in. | ‑ N | ‑ N | 0.42 lbs. |
| RLS‑8‑NR | 1 in. | 2‑1/4 in. | 5/8 in. | 1 N | 9 N | 0.42 lbs. |
| RMS 8 | 1 in. | 2‑1/2 in. | 3/4 in. | 1 N | 1 N | 0.25 lbs. |
| RLS‑4 | 1/2 in. | 1‑5/16 in. | 3/8 in. | 5 N | 3 N | 0.12 lbs. |
| RLS‑4‑2RS | 1/2 in. | 1‑5/16 in. | 3/8 in. | ‑ N | ‑ N | 0.12 lbs. |
| RLS‑4‑2Z | 1/2 in. | 1‑5/16 in. | 3/8 in. | ‑ N | ‑ N | 0.12 lbs. |
| RMS 4 | 1/2 in. | 1‑5/8 in. | 5/8 in. | 9 N | 5 N | 0.10 lbs. |
| RLS‑12 | 1‑1/2 in. | 3‑1/4 in. | 3/4 in. | 2 N | 1 N | 1.10 lbs. |
| RLS‑12‑2RS | 1‑1/2 in. | 3‑1/4 in. | 3/4 in. | ‑ N | ‑ N | 1.10 lbs. |
| RLS‑12‑2Z | 1‑1/2 in. | 3‑1/4 in. | 3/4 in. | ‑ N | ‑ N | 1.10 lbs. |
| RLS‑28 | 1‑1/2 in. | 6‑1/2 in. | 1‑1/8 in. | ‑ N | ‑ N | 6.20 lbs. |
| RMS 12 | 1‑1/2 in. | 3‑3/4 in. | 15/16 in. | 4 N | 2 N | 0.79 lbs. |
| XLS‑1 1/2 | 1‑1/2 in. | 2‑11/16 in. | 9/16 in. | ‑ N | ‑ N | 0.44 lbs. |
| RLS‑10 | 1‑1/4 in. | 2‑3/4 in. | 11/16 in. | 1 N | 1 N | 0.63 lbs. |
| RLS‑10‑2RS | 1‑1/4 in. | 2‑3/4 in. | 11/16 in. | ‑ N | ‑ N | 0.63 lbs. |
| RLS‑10‑2Z | 1‑1/4 in. | 2‑3/4 in. | 11/16 in. | ‑ N | ‑ N | 0.63 lbs. |
| RLS‑10‑NR | 1‑1/4 in. | 2‑3/4 in. | 11/16 in. | 1 N | 1 N | 0.63 lbs. |
| RMS 10 | 1‑1/4 in. | 3‑1/8 in. | 7/8 in. | 2 N | 1 N | 0.51 lbs. |
| RLS‑9 | 1‑1/8 in. | 2‑1/2 in. | 5/8 in. | 1 N | 1 N | 0.51 lbs. |
| RLS‑9‑2RS | 1‑1/8 in. | 2‑1/2 in. | 5/8 in. | ‑ N | ‑ N | 0.51 lbs. |
| RLS‑9‑2Z | 1‑1/8 in. | 2‑1/2 in. | 5/8 in. | ‑ N | ‑ N | 0.51 lbs. |
| RLS‑9‑NR | 1‑1/8 in. | 2‑1/2 in. | 5/8 in. | 1 N | 1 N | 0.51 lbs. |
| RMS 9 | 1‑1/8 in. | 2‑13/16 in. | 13/16 in. | 1 N | 1 N | 0.38 lbs. |
| RLS‑14 | 1‑3/4 in. | 3‑3/4 in. | 13/16 in. | ‑ N | ‑ N | 1.61 lbs. |
| RLS‑14‑2RS | 1‑3/4 in. | 3‑3/4 in. | 13/16 in. | ‑ N | ‑ N | 1.61 lbs. |
| RLS‑14‑2Z | 1‑3/4 in. | 3‑3/4 in. | 13/16 in. | ‑ N | ‑ N | 1.61 lbs. |
| XLS‑1 3/4 | 1‑3/4 in. | 3 in. | 9/16 in. | ‑ N | ‑ N | 0.53 lbs. |
| RLS‑11 | 1‑3/8 in. | 3 in. | 11/16 in. | 2 N | 1 N | 0.87 lbs. |
| RLS‑11‑2RS | 1‑3/8 in. | 3 in. | 11/16 in. | ‑ N | ‑ N | 0.87 lbs. |
| RLS‑11‑2Z | 1‑3/8 in. | 3 in. | 11/16 in. | ‑ N | ‑ N | 0.87 lbs. |
| RLS‑11‑NR | 1‑3/8 in. | 3 in. | 11/16 in. | 2 N | 1 N | 0.87 lbs. |
| RMS 11 | 1‑3/8 in. | 3‑1/2 in. | 7/8 in. | 4 N | 2 N | 0.63 lbs. |
| XLS‑1 3/8 | 1‑3/8 in. | 2‑9/16 in. | 9/16 in. | ‑ N | ‑ N | 0.40 lbs. |
| RLS‑13 | 1‑5/8 in. | 3‑1/2 in. | 3/4 in. | ‑ N | ‑ N | 1.29 lbs. |
| XLS‑1 5/8 | 1‑5/8 in. | 2‑7/8 in. | 9/16 in. | ‑ N | ‑ N | 0.63 lbs. |
| RLS‑15 | 1‑7/8 in. | 4 in. | 13/16 in. | ‑ N | ‑ N | 1.85 lbs. |
| XLS‑1 7/8 | 1‑7/8 in. | 3‑3/16 in. | 5/8 in. | ‑ N | ‑ N | 0.81 lbs. |
| RLS‑16 | 2 in. | 4 in. | 13/16 in. | ‑ N | ‑ N | 1.78 lbs. |
| XLS‑2 | 2 in. | 3‑5/16 in. | 5/8 in. | ‑ N | ‑ N | 0.88 lbs. |
| RLS‑20 | 2‑1/2 in. | 5 in. | 15/16 in. | ‑ N | ‑ N | 3.15 lbs. |
| XLS‑2 1/2 | 2‑1/2 in. | 3‑7/8 in. | 11/16 in. | ‑ N | ‑ N | 1.13 lbs. |
| RLS‑18 | 2‑1/4 in. | 4‑1/2 in. | 7/8 in. | ‑ N | ‑ N | 2.40 lbs. |
| XLS‑2 1/4 | 2‑1/4 in. | 3‑9/16 in. | 5/8 in. | ‑ N | ‑ N | 0.91 lbs. |
| XLS‑2 1/8 | 2‑1/8 in. | 3‑7/16 in. | 5/8 in. | ‑ N | ‑ N | 0.78 lbs. |
| RLS‑22 | 2‑3/4 in. | 5‑1/2 in. | 15/16 in. | ‑ N | ‑ N | 3.40 lbs. |
| XLS‑2 3/4 | 2‑3/4 in. | 4‑1/8 in. | 11/16 in. | ‑ N | ‑ N | 1.09 lbs. |
| XLS‑2 3/8 | 2‑3/8 in. | 3‑3/4 in. | 11/16 in. | ‑ N | ‑ N | 0.90 lbs. |
| XLS‑2 5/8 | 2‑5/8 in. | 4‑1/8 in. | 11/16 in. | ‑ N | ‑ N | 1.25 lbs. |
| XLS‑2 7/8 | 2‑7/8 in. | 4‑1/2 in. | 3/4 in. | ‑ N | ‑ N | 1.67 lbs. |
| RLS‑24 | 3 in. | 5‑3/4 in. | 1‑1/16 in. | ‑ N | ‑ N | 4.65 lbs. |
| XLS‑3 | 3 in. | 4‑1/2 in. | 3/4 in. | ‑ N | ‑ N | 1.56 lbs. |
| RLS‑6 | 3/4 in. | 1‑7/8 in. | 9/16 in. | 1 N | 6 N | 0.28 lbs. |
| RLS‑6‑2RS | 3/4 in. | 1‑7/8 in. | 9/16 in. | ‑ N | ‑ N | 0.28 lbs. |
| RLS‑6‑2Z | 3/4 in. | 1‑7/8 in. | 9/16 in. | ‑ N | ‑ N | 0.28 lbs. |
| RMS 6 | 3/4 in. | 2 in. | 11/16 in. | 1 N | 8 N | 0.16 lbs. |
| XLS‑3 1/2 | 3‑1/2 in. | 5 in. | 3/4 in. | ‑ N | ‑ N | 1.75 lbs. |
| RLS‑26 | 3‑1/4 in. | 6 in. | 1‑1/16 in. | ‑ N | ‑ N | 4.90 lbs. |
| XLS‑3 1/4 | 3‑1/4 in. | 4‑3/4 in. | 3/4 in. | ‑ N | ‑ N | 1.53 lbs. |
| XLS‑3 1/8 | 3‑1/8 in. | 4‑3/4 in. | 3/4 in. | ‑ N | ‑ N | 1.61 lbs. |
| RLS‑30 | 3‑3/4 in. | 6‑3/4 in. | 1‑1/8 in. | ‑ N | ‑ N | 6.70 lbs. |
| XLS‑3 3/4 | 3‑3/4 in. | 5‑1/4 in. | 3/4 in. | ‑ N | ‑ N | 1.84 lbs. |
| XLS‑3 3/8 | 3‑3/8 in. | 5 in. | 3/4 in. | ‑ N | ‑ N | 1.84 lbs. |
| XLS‑3 5/8 | 3‑5/8 in. | 5‑1/4 in. | 3/4 in. | ‑ N | ‑ N | 2.01 lbs. |
| XLS‑3 7/8 | 3‑7/8 in. | 5‑5/8 in. | 7/8 in. | ‑ N | ‑ N | 2.63 lbs. |
| RLS‑32 | 4 in. | 7‑1/4 in. | 1‑1/4 in. | ‑ N | ‑ N | 8.80 lbs. |
| XLS‑4 | 4 in. | 5‑5/8 in. | 7/8 in. | ‑ N | ‑ N | 2.50 lbs. |
| RLS‑36 | 4‑1/2 in. | 8 in. | 1‑5/16 in. | ‑ N | ‑ N | 11.20 lbs. |
| XLS‑4 1/2 | 4‑1/2 in. | 6‑1/4 in. | 7/8 in. | ‑ N | ‑ N | 3.02 lbs. |
| RLS‑34 | 4‑1/4 in. | 7‑1/2 in. | 1‑1/4 in. | ‑ N | ‑ N | 9.15 lbs. |
| XLS‑4 1/4 | 4‑1/4 in. | 6 in. | 7/8 in. | ‑ N | ‑ N | 2.87 lbs. |
| XLS‑4 1/8 | 4‑1/8 in. | 6 in. | 7/8 in. | ‑ N | ‑ N | 3.00 lbs. |
| RLS‑38 | 4‑3/4 in. | 8‑1/4 in. | 1‑5/16 in. | ‑ N | ‑ N | 11.40 lbs. |
| XLS‑4 3/4 | 4‑3/4 in. | 6‑1/2 in. | 7/8 in. | ‑ N | ‑ N | 3.10 lbs. |
| XLS‑4 3/8 | 4‑3/8 in. | 6‑1/4 in. | 7/8 in. | ‑ N | ‑ N | 3.13 lbs. |
| XLS‑4 5/8 | 4‑5/8 in. | 6‑1/2 in. | 7/8 in. | ‑ N | ‑ N | 3.34 lbs. |
| XLS‑4 7/8 | 4‑7/8 in. | 7 in. | 1 in. | ‑ N | ‑ N | 4.59 lbs. |
| RLS‑40 | 5 in. | 9 in. | 1‑3/8 in. | ‑ N | ‑ N | 15.00 lbs. |
| XLS‑5 | 5 in. | 7 in. | 1 in. | ‑ N | ‑ N | 4.50 lbs. |
| RLS‑5 | 5/8 in. | 1‑9/16 in. | 7/16 in. | 7 N | 4 N | 0.16 lbs. |
| RLS‑5‑2RS | 5/8 in. | 1‑9/16 in. | 7/16 in. | ‑ N | ‑ N | 0.16 lbs. |
| RLS‑5‑2Z | 5/8 in. | 1‑9/16 in. | 7/16 in. | ‑ N | ‑ N | 0.16 lbs. |
| RMS 5 | 5/8 in. | 1‑13/16 in. | 5/8 in. | 1 N | 6 N | 0.11 lbs. |
| RLS‑44 | 5‑1/2 in. | 9‑1/2 in. | 1‑3/8 in. | ‑ N | ‑ N | 15.60 lbs. |
| XLS‑5 1/2 | 5‑1/2 in. | 7‑1/2 in. | 1 in. | ‑ N | ‑ N | 4.51 lbs. |
| XLS‑5 1/4 | 5‑1/4 in. | 7‑1/4 in. | 1 in. | ‑ N | ‑ N | 4.69 lbs. |
| XLS‑5 1/8 | 5‑1/8 in. | 7‑1/4 in. | 1 in. | ‑ N | ‑ N | 4.75 lbs. |
| XLS‑5 3/4 | 5‑3/4 in. | 7‑3/4 in. | 1 in. | ‑ N | ‑ N | 4.80 lbs. |
| XLS‑5 3/8 | 5‑3/8 in. | 7‑1/2 in. | 1 in. | ‑ N | ‑ N | 5.00 lbs. |
| XLS‑5 5/8 | 5‑5/8 in. | 7‑3/4 in. | 1 in. | ‑ N | ‑ N | 5.13 lbs. |
| XLS‑5 7/8 | 5‑7/8 in. | 8 in. | 1 in. | ‑ N | ‑ N | 5.40 lbs. |
| RLS‑48 | 6 in. | 10‑1/2 in. | 1‑9/16 in. | ‑ N | ‑ N | 20.90 lbs. |
| XLS‑6 | 6 in. | 8 in. | 1 in. | ‑ N | ‑ N | 5.25 lbs. |
| RLS‑52 | 6‑1/2 in. | 11 in. | 1‑9/16 in. | ‑ N | ‑ N | 22.50 lbs. |
| XLS‑6 1/2 | 6‑1/2 in. | 8‑3/4 in. | 1‑1/8 in. | ‑ N | ‑ N | 7.56 lbs. |
| XLS‑6 1/4 | 6‑1/4 in. | 8‑1/2 in. | 1‑1/8 in. | ‑ N | ‑ N | 6.73 lbs. |
| XLS‑6 3/4 | 6‑3/4 in. | 9 in. | 1‑1/8 in. | ‑ N | ‑ N | 7.03 lbs. |
| RLS‑56 | 7 in. | 12 in. | 1‑3/4 in. | ‑ N | ‑ N | 31.00 lbs. |
| XLS‑7 | 7 in. | 9‑1/2 in. | 1‑1/4 in. | ‑ N | ‑ N | 9.56 lbs. |
| RLS‑7 | 7/8 in. | 2 in. | 9/16 in. | 1 N | 7 N | 0.32 lbs. |
| RLS‑7‑2RS | 7/8 in. | 2 in. | 9/16 in. | ‑ N | ‑ N | 0.32 lbs. |
| RLS‑7‑2Z | 7/8 in. | 2 in. | 9/16 in. | ‑ N | ‑ N | 0.32 lbs. |
| RMS 7 | 7/8 in. | 2‑1/4 in. | 11/16 in. | 1 N | 9 N | 0.20 lbs. |
| RLS‑60 | 7‑1/2 in. | 12‑1/2 in. | 1‑3/4 in. | ‑ N | ‑ N | 32.00 lbs. |
| XLS‑7 1/2 | 7‑1/2 in. | 10 in. | 1‑1/4 in. | ‑ N | ‑ N | 10.25 lbs. |
| XLS‑7 1/4 | 7‑1/4 in. | 9‑3/4 in. | 1‑1/4 in. | ‑ N | ‑ N | 10.10 lbs. |
| XLS‑7 3/4 | 7‑3/4 in. | 10‑1/2 in. | 1‑3/8 in. | ‑ N | ‑ N | 12.50 lbs. |
| RLS‑64 | 8 in. | 13 in. | 1‑3/4 in. | ‑ N | ‑ N | 35.00 lbs. |
| XLS‑8 | 8 in. | 10‑3/4 in. | 1‑3/8 in. | ‑ N | ‑ N | 13.00 lbs. |
| RLS‑68 | 8‑1/2 in. | 14 in. | 2 in. | ‑ N | ‑ N | 46.50 lbs. |
| XLS‑8 1/2 | 8‑1/2 in. | 11‑1/2 in. | 1‑1/2 in. | ‑ N | ‑ N | 17.00 lbs. |
| XLS‑8 1/4 | 8‑1/4 in. | 11 in. | 1‑3/8 in. | ‑ N | ‑ N | 13.50 lbs. |
| XLS‑8 3/4 | 8‑3/4 in. | 11‑3/4 in. | 1‑1/2 in. | ‑ N | ‑ N | 17.38 lbs. |
| RLS‑72 | 9 in. | 14‑1/2 in. | 2 in. | ‑ N | ‑ N | 49.75 lbs. |
| XLS‑9 | 9 in. | 12 in. | 1‑1/2 in. | ‑ N | ‑ N | 17.87 lbs. |
| RLS‑73 | 9‑1/2 in. | 15‑1/8 in. | 2 in. | ‑ N | ‑ N | 50.00 lbs. |
| XLS‑9 1/2 | 9‑1/2 in. | 12‑3/4 in. | 1‑5/8 in. | ‑ N | ‑ N | 22.00 lbs. |
| RLS‑80 | 10 in. | 15‑3/4 in. | 2 in. | ‑ N | ‑ N | 56.30 lbs. |
| XLS‑10 | 10 in. | 13‑1/4 in. | 1‑5/8 in. | ‑ N | ‑ N | 23.00 lbs. |
| RLS‑81 | 10‑1/2 in. | 16‑5/8 in. | 2‑1/4 in. | ‑ N | ‑ N | 71.70 lbs. |
| XLS‑10 1/2 | 10‑1/2 in. | 14 in. | 1‑3/4 in. | ‑ N | ‑ N | 28.10 lbs. |
| RLS‑88 | 11 in. | 17‑1/2 in. | 2‑1/4 in. | ‑ N | ‑ N | 79.60 lbs. |
| XLS‑11 | 11 in. | 14‑1/2 in. | 1‑3/4 in. | ‑ N | ‑ N | 29.30 lbs. |
| RLS‑89 | 11‑1/2 in. | 18 in. | 2‑3/8 in. | ‑ N | ‑ N | 84.90 lbs. |
| XLS‑11 1/2 | 11‑1/2 in. | 15‑1/4 in. | 1‑7/8 in. | ‑ N | ‑ N | 35.30 lbs. |
| RLS‑92 | 12 in. | 18‑1/2 in. | 2‑5/8 in. | ‑ N | ‑ N | 98.00 lbs. |
| XLS‑12 | 12 in. | 16 in. | 2 in. | ‑ N | ‑ N | 41.06 lbs. |
| XLS‑12 1/2 | 12‑1/2 in. | 16‑1/2 in. | 2 in. | ‑ N | ‑ N | 43.80 lbs. |
| RLS‑93 | 13 in. | 20 in. | 2‑3/4 in. | ‑ N | ‑ N | 114.00 lbs. |
| XLS‑13 | 13 in. | 17‑1/2 in. | 2‑1/4 in. | ‑ N | ‑ N | 58.30 lbs. |
| XLS‑13 1/2 | 13‑1/2 in. | 18 in. | 2‑1/4 in. | ‑ N | ‑ N | 60.40 lbs. |
| RLS‑94 | 14 in. | 21‑1/2 in. | 2‑7/8 in. | ‑ N | ‑ N | 144.00 lbs. |
| XLS‑14 | 14 in. | 18‑1/2 in. | 2‑1/4 in. | ‑ N | ‑ N | 62.50 lbs. |
| XLS‑14 1/2 | 14‑1/2 in. | 19‑1/2 in. | 2‑1/2 in. | ‑ N | ‑ N | 80.00 lbs. |
| RLS‑95 | 15 in. | 22‑1/2 in. | 3 in. | ‑ N | ‑ N | 157.00 lbs. |
| XLS‑15 | 15 in. | 20 in. | 2‑1/2 in. | ‑ N | ‑ N | 82.30 lbs. |
| XLS‑15 1/2 | 15‑1/2 in. | 20‑1/2 in. | 2‑1/2 in. | ‑ N | ‑ N | 85.56 lbs. |
| XLS‑16 | 16 in. | 21‑1/2 in. | 2‑3/4 in. | ‑ N | ‑ N | 107.00 lbs. |
| XLS‑16 1/2 | 16‑1/2 in. | 22 in. | 2‑3/4 in. | ‑ N | ‑ N | 110.00 lbs. |
| XLS‑17 | 17 in. | 22‑1/2 in. | 2‑3/4 in. | ‑ N | ‑ N | 113.00 lbs. |
| XLS‑17 1/2 | 17‑1/2 in. | 23‑1/2 in. | 3 in. | ‑ N | ‑ N | 139.00 lbs. |
| XLS‑18 | 18 in. | 24 in. | 3 in. | ‑ N | ‑ N | 142.00 lbs. |
| XLS‑18 1/2 | 18‑1/2 in. | 24‑1/2 in. | 3 in. | ‑ N | ‑ N | 145.00 lbs. |
| XLS‑19 | 19 in. | 25‑1/2 in. | 3‑1/4 in. | ‑ N | ‑ N | 176.00 lbs. |
| XLS‑19 1/2 | 19‑1/2 in. | 26 in. | 3‑1/4 in. | ‑ N | ‑ N | 180.00 lbs. |
| XLS‑20 | 20 in. | 26‑1/2 in. | 3‑1/4 in. | ‑ N | ‑ N | 184.00 lbs. |
| XLS‑20 1/2 | 20‑1/2 in. | 27‑1/2 in. | 3‑1/2 in. | ‑ N | ‑ N | 221.00 lbs. |
| XLS‑21 | 21 in. | 28 in. | 3‑1/2 in. | ‑ N | ‑ N | 227.00 lbs. |
